Round Mica Insulated Air Cooling Heaters
MH-404
Air Cooling heaters are mainly used in extruder and recyling machines.
In some cases, it is also used for the processing of PVC or similar materials in injection molding machines.
It is procuded according customer's demand.
| Technical Specification | |
| Diameter : | Min. Ø60mm - Max. Ø600mm. |
| Length: | Min 100mm - Max. 800mm. |
| Voltage: | 230/400 V |
| Wattage : | Max. 3,5 W/cm² |
| Height of Cover: | 35 mm |
| Cover Shape: | Round |
| Working Temperature: | 280 °C |
| Housing Material: | Stainless Steel or Aluminised Sheet |
| Insulation Material: | 800-1000 °C Micanite |
| Resistance Winding Wire: | 60/15 NiCr 1200°C |
| Energy Connection : | Ni GLS Cable Resistant to 400ºC , and connection box |
